13 Installer Guide
Thermal Insulating Sheet
A label is provided on the backplate that
prevents drafts originating inside the wall
from entering the thermostat.
These drafts, left unchecked, may cause
incorrect room temperature readings.
Please do not remove this label from
the thermostat. Insert the wires
through the slots provided in
the label as shown in Fig. 1.
Wire
Slots
CO/B YWGRCRH
4Z95
MODEL: PSP1100
97061606
MADE IN CHINA
USE SIZE “AA”
ALKALINE BATTERIES
FIG. 1
