Check Jumpers (ONLY for PSP1100)
Ensure which jumper is correct for your system.
Jumpers are located on the back of the thermostat.
J1 = GAS the thermostat will not energize the Fan (G)
terminal in heating.
J1 = ELEC the thermostat will energize the fan in
heating.
J2 = GAS/ELEC the thermostat is configured for a
conventional gas/electric system
J2 = HP the thermostat is configured for a heat pump
system.
Heat Pump Systems Only (J2 = HP)
J3 = O reversing valve terminal O/B will energize
in cooling
J3 = B reversing valve terminal O/B will energize
in heating
