3. Mount the System
• Position the bracket to allow for the height and width of the unit.
• Mount the bracket with the two holes at the top and the single
hole at the bottom.
• Tilt the top of the unit towards the wall and slide the retainer
band up and into the upper notch on the bracket. Straighten the
unit and let the bottom of the retainer band set into the lower
notch.
4. Connect the Inlet Shut Off Valve (Not Supplied)
• Use 1/4 inch OD tubing (not supplied) to connect the inlet shut
off valve to the inlet of the filter housing (see figure 4). To secure
the connection, press the tubing in firmly.
5. Install the Faucet
•Install the flow restictor in 3/8 inch OD tubing (not supplied)
connected to the outlet of the filter housing.
• Connect the new faucet to the outlet of the filter housing (see
figure 4). To secure the connection, press the tubing in firmly.
• For an ice maker connection, install a tee (not supplied) between
the outlet and the new faucet. Connect the tubing to the ice
maker (see figure 4).
System Start Up
1. Turn on the Cold Water Supply
• Allow water to enter the system and let it stand for 5 minutes.
2. Check for Leaks
• If a leak is present, make the necessary repairs.
3. Flush the System
• Open the new faucet and allow the water to flow for 30 minutes.
This process will flush the disinfectant and carbon fines from the
system.
5
Helpful Tip: Additional flushing may be
required if carbon fines are still present in
the water.
Helpful Tip: Use quick disconnect fittings or
add extra tubing for easy system removal
during filter changes. Coil the extra tubing
so it is out of the way.
Helpful Tip: Use quick disconnect fittings or
add extra tubing for easy system removal
during filter changes. Coil the extra tubing
so it is out of the way.
