Protec AC-200-dual - Equipment Description; Component Locations

TEKTINO AC-200-dual USER MANUAL V2.30
4
/14
Equipment description
Front view
Back view
Left view
Right view
Key pad
LP gauge
R134a/HFO1234yf
Coupler connect
fittings
LCD screen
HP gauge
Fuse
Power
switch
Vacuum pump
New oil
vessel
Used oil
vessel
R134a
refrigerant tank
HFO1234yf
Refrigerant tank
R134a tank
gauge
Non-condensable
purge valve for
R134a tank
HFO1234yf
tank gauge
Non-condensable
purge valve for
HFO1234yf tank
