5.3 User Indicator Summary
Red
Master handset off hook
Flashing Yellow
Master handset open circuit
Cyan
User logged in
Magenta
Engineer logged in
Flashing green
Call connected
Flashing Red/Green
Call on hold
Solid Yellow
Master handset short circuit
Solid White
Call connected on remote master station
5.4 Zone indicator summary
Zone Indicator
Status
User Indicator
Status
Buzzer
Status
Description
Slow flash red
Off
Outgoing call
Fast flash red
Ringing
Incoming call from type A
outstation
Normal flash red
Ringing
Incoming call from type B
outstation
Normal flash green
Normal flash green
Off
Call connected to local master
handset
Normal flash
green/red
Normal flash
green/red
Off
Call on hold
Normal flash
green/white
Solid White
Off
Call connected via a remote master
handset
Solid yellow
On
Line Short circuited
Slow flash yellow
On
Line card missing
Normal flash yellow
On
Line Open circuit or EOL missing
Fast flash yellow
On
Line Earth fault
Solid cyan
Solid cyan
Off
Access level 2
Solid magenta
Solid magenta
Off
Access level 3
Normal flash blue
2 Tone Alarm
Incoming Assist Call alarm
Solid blue
Intermittent
double Beep
Assist call acknowledged
