6
When the outside temperature is below 0°C (32°F), recovery (of heat or energy)
creates frost in the core.To maintain its proper operation, the unit is programmed
to defrost the recovery core. The defrost frequency varies according to the
outside temperature. Defrosting lasts 6 minutes. During the defrost cycle, the
unit shifts to maximum speed and the dampers close.
After defrosting, the unit returns to the operating mode selected by the user.
1.4 DEFROSTING
1.5 SPECIFICATIONS
Model 84 HRV100 / ERV100
Width 30 1/4“ (768 mm)
Height 20“ (508 mm)
Depth 13 3/4“ (349 mm)
Weight 65 lbs (30 kg)
Electrical Supply 120 V, 60 Hz
Power Consumption 150 Watts
Model 84 HRV200 / ERV200
Width 30 1/4“ (768 mm)
Height 20“ (508 mm)
Depth 19“ (483 mm)
Weight 73 lbs (33 kg)
Electrical Supply 120 V, 60 Hz
Power Consumption 225 Watts
