protech EVO COMPACT User Manual

Page | 26
ROCK SPIKE CONTROL
______________________________________________________________________
Before using the rock spike the weight will have to be raised so that the rock spike can
be moved into position.
The rock spike is located on a support pin when not in use. Raise the rock spike using
the control lever to give clearance, then manually swing into position.
The rock spike control valve is used to maintain sufficient clearance of the support collar
from the head of the rock spike.
TRAPPING POINT
CRUSHING ZONE
