6. Use the `Right Track` lever to rotate the drill and `Rock Spike` lever to lower the
drill
7. On completion, `right track` forward and `rock spike` up.
8. Lift the weight up clear of the auger.
9. Use the `rock spike` lever to swing the auger clear of the mast
10. AUGER CONTROLS
The recessed screw controls the hydraulic power to the auger motor.
The speed control is `clockwise` to slow down and `counter clockwise` to speed up
