Chapter 2 Hardware Configuration
Page: 2-26
Prox-1260 USER
′
S MANUAL
2-36. LVDS/ LCD2 PANEL POWER SELECTION
JP3 : LCD_VCC Power Selection.
The selections are as follows:
SELECTION JUMPER SETTING
JUMPER
ILLUSTRATION
LCD_VCC3
1-3
2-4
LCD_VCC5
3-5
4-6
