4-6. INTEGRATED PERIPHERALS
Choose〝INTEGRATED PERIPHERALS〞from the main setup menu, a
display will be shown on screen as below:
Phoenix - AwardBIOS CMOS Setup Utility
Integrated Peripherals
On-Chip IDE Channel0 [Enabled] Item Help
IDE Prefetch Mode
Primary Master PIO
Primary Slave PIO
Primary Master UDMA
Primary Slave UDMA
Init Display First
IDE HDD Block Mode
Onboard FDD Controller
Onboard Serial Port 1
Onboard Serial Port 2
UART 2 Mode
x IR Function Duplex
x TX,RX inverting enable
Onboard Parallel Port
Onboard Parallel Mode
x ECP Mode Use DMA
x Parallel Port EPP Type
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[PCI Slot]
[Enabled]
[Enabled]
[Auto]
[Auto]
[Standard]
Half
No, Yes
[378/IRQ7]
[Normal]
3
EPP1.9
Menu Level
►
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Integrated Peripherals Setup Screen
By moving the cursor to the desired selection and by pressing the <F1> key,
the all options for the desired selection will be displayed for choice.
ONCHIP IDE CHANNEL 0:
The chipset contains a PCI IDE interface with support for two IDE
channels. Select Enabled to activate the primary IDE interface. Select
Disabled to deactivate this interface.
IDE PREFETCH MODE:
The onboard IDE drive interfaces supports IDE pre-fetching for faster drive
accesses. If you install a primary and or secondary add-in IDE interface,
set this field to Disabled if the interface does not support pre-fetching.
