Chapter 4 Award BIOS Setup
Page: 4-18
Prox-1260 USER
′
S MANUAL
TX, RX INVERTING ENABLE:
This item allows you to enable TX, RX inverting which depends on
different H/W requirement. This field is not recommended to change its
default setting for avoiding any error in your system.
ONBOARD PARALLEL PORT:
This item allows you to determine access onboard parallel port controller with
which I/O address.
ONBOARD PARALLEL MODE:
Select an operating mode for the onboard (printer) port. Select Normal
unless you are certain your hardware and software both support one of the
other available modes.
ECP MODE USE DMA:
Select a DMA channel for the parallel port for use during ECP mode.
PARALLEL PORT EPP TYPE:
Select EPP port type 1.7 or 1.9 as required by your parallel peripheral.
