VR1- AUTOMATIC CLOSING
VR1 trimmer sets the automatic closing time (DIP-switch 2 = ON).
The automatic closing time can be adjusted between 1 and 60 seconds.
VR2- FORCE IN OPENING
VR2 trimmer sets the force and the obstacle detection. Turning the trimmer
clockwise the force increases while the obstacle detection decreases. Calibrate the
obstacle detection force properly, to avoid faults during normal operation. We
recommend to start setting the force to minimum and after
adjust step by step
VR3- FORCE IN CLOSING
VR3 trimmer sets the force and the obstacle detection. Turning the trimmer
clockwise the force increases while the obstacle detection decreases. Calibrate the
obstacle detection force properly, to avoid faults during normal operation. We
recommend to start setting the force to minimum and after adjust step by step
DIP-switch
DIP-switch 1:
ON - Automatic closing ACTIVATED
OFF - Automatic closing DEACTIVATED
DIP-switch 2:
ON - The flashing light is OFF when the barrier is in stand-by .
OFF - The flashing light is ON when the barrier is in stand-by.
LED Work
OPEN
STOP
CLOSE
LEARN
The barrier is opening
The barrier is in stand-by
The barrier is closing
Transmitter storage in progress
LED Warnings
DS2
DS3
DS4
DS5
DS1
Opening completed
Closing completed
Safety edge / loop detector operating
Photocells calibrated
Barrier powered
TIME
OPEN_FORCE
VR3
CLOSE_FORCE
OPEN STOP CLOSE
LED1 LED2 LED3
