4
B
C rx 4 x 0,50 mm²
C¹ tx 2 x 0,50 mm²
D
E
mm²
mm²
2 x 0,50
2 x 0,50
A
a
b
e
d
c
c
a
c1
c1
fig. B
3 x 1,5 mm² + Terra
2 x 1,5 mm² + Terra
2 x 1,5 mm²
2 x 1,5 mm² + Terra
rx 4 x 0,50 mm²
tx 2 x 0,50 mm²
2 x 0,50
2 x 0,50
mm²
mm²
B
C
C¹
D
E
A
3.3 WIRING INSTALLATION OVERVIEW
N.B.: The number of tubes and cables
(not included in the kit) depends on the type of
the accessories employed
Cut off the power before starting wiring
A circuit breaker should be fitted close to the gate (3 mm wires) to protect both the gate control panel and the house main fuse box. A 6A
automatic breaker or a 16A single phase breaker complete with fuses shall be suitable.
Make sure you have suitable tubing and conduits for the electrical cables: feed the motors, control panel and accessories separately, in order to
prevent interferences that may result in bad operation.
Fit the power cable keeping a curve as shown in picture B, in order to avoid water blackflow inside the operator. (pic. B)
(pic. A)
Ram
Control panel
Photocells
Photocells
Key switch
Flashing light
Ram
Control panel
Photocells
Photocells
Key switch
Flashing light
CABLES NEEDED
230V 24V
PROPERTY VIEW
