1. WARNINGS
This manual for MATRIX series contains important information concerning personal safety.
An incorrect installation or an improper use may lead to severe injuries.
Read carefully and pay particular attention to the safety sections marked by the yellow triangle .
The installation of automatic doors, gates and barriers must comply with the Machinery Directive 2006/42/CE and EN 12453 regulation,
and performed by qualied personnel.
Make sure the main power line is equipped with state of the art safety grounding system; as well be sure the whole installation is
protected by a power cut switch and against overcurrent.
Make sure the area is clear from flammable gases and/or electromagnetic interferences: it could lead to very dangerous injuries.
Switch the power and batteries OFF before any operation.
After installation, packaging and waste materials (cardboard, plastic, metal parts etc.) must be kept away from children as they could be
potentially harmfull. Use only original spare parts. Any alteration to the system is prohibited.
Proteco Srl will not respond in case of using additional and/or fake spares.
Before commissioning the system, deliver the last pages of this manual to the user (section 5. END USER’S TIPS starting from page 13).
Proteco S.r.l. reserves the right to make changes to the product without notice.
2. TECHNICAL FEATURES
2.1 Introduction
MATRIX range is the new Proteco's electromechanical rack-driven motor generation designed to automate sliding gates in residential, block and
industrial areas.
Any other use than that described is to be considered improper and prohibited.
All models grant the mechanical locking of the gate with an irreversible gear system; it is therefore not necessary to install any type of lock.
MATRIX works by electricity, in case of power cut the motor can be manually unlocked using a special lever system protected by key.
Matrix 2500 Matrix 1800 Matrix BLDC Matrix High Speed
Power supply 230 V 50/60 Hz 230 V 50/60 Hz 230 V 50/60 Hz 230 V 50/60 Hz
Motor voltage 6 A 4,5 A 4,5 A 3 A
Start up current 2,5 A 2 A 1,4 A 1,3 A
Rated current 230 V 50/60 Hz 230 V 50/60 Hz 48 V dc 48 V dc
Rated power 550W 500W 350W 300W
Start up capacitor 25 µF 30 µF - -
Standard capacitor 25 µF 20 µF - -
Start up thrust 2000 N 1400 N 1600 N 1400 N
Rated thrust
1100 N 900 N 1000 N 700 N
Thermal cut off 150°C 150°C - -
Max. opening speed 11 m/min 11 m/min 13 m/min 20 m/min
Max. leaf weight
2500 Kg 1800 Kg 2500 Kg 1800 Kg
Duty cycle
50% 50%
80% 80%
Operating temperature -30° C ÷ + 55° C -30° C ÷ + 55° C -30° C ÷ + 55° C -30° C ÷ + 55° C
IP rating 44 44 44 44
Limit switch type
Mechanical/
Magnetic
2.2 Technical features
Mechanical/
Magnetic
Mechanical
/
Magnetic
Mechanical/
Magnetic
Fuse 8A 8A 5A + 30A@48V 5A + 30A@48V
