Proteus EEC - 3000 - Parts List

- 1 -
PARTS LIST
KEY. DESCRIPTION Q'TY KEY. DESCRIPTION Q'TY
1. MAIN FRAME 1
28. SPACER X 49mm 2
2. HANDLEBAR POST 1
29. SPACER X 32mm 2
3. HANDRAIL 2
30. FOAM GRIP X 360mm 2
4. CONNECTING ARM 2
31. FOAM GRIP X 130mm 2
5. PEDAL ARM 2
32. 33 PU WHEEL 8
6. HOLDER 2
33. M8 CARRIAGE BOLT X 70mm 4
7. COMPUTER 1
34. M8 BOLT X 75mm 2
8. EXTENSION CABLE WIRE 1
35. M8 BOLT X 35mm 8
9. LOWER CABLE WIRE 1
36. M8 BOLT X 15mm 4
10. GRIP PULSE WIRE 1
37. M6 SCREW X 70mm 4
11. GRIP PULSE 2
38. M6 SCREW X 15mm 8
12. SLIDE TUBE 2
39. M5 SCREW X 20mm 4
13. AXLE SPACER 2
40. M6 SCREW X 15mm 2
14. PIVOT CAP - A 2
41. STUD SHAFT 2
15. PIVOT CAP - B 2
42. M8 BIG WASHER 14
16. FOOT PEDAL 2
43. M8 MIDDLE WASHER 2
17. CHAIN COVER ( R ) 1
44. M8 SMALL WASHER 14
18. CHAIN COVER ( L ) 1
45. M6 WASHER 10
19. CRANK COVER 2
46. M8 NYLON NUT 18
20. HALF MOON CAP 14
47. M8 HALF MOON CAP 4
21. CAP 2
48. M6 NYLON NUT 4
22. FOOT ADJUSTBASE 2
49. BEARING 6003ZZ ( S ) 4
23. FOOT CAP 2
50. BEARING 6003ZZ 16
24. SLIDE TUBE PLUG 4
55. SPACER X 4mm 8
25. 25 X 50 PLUG 2
56. WHEEL RACK ( R ) 2
26. 38 ROUND PLUG 4
57. WHEEL RACK ( L ) 2
27. SPACER X 60mm 6
58. M8 BOLT X 85mm 4
