Proteus PEC-2035 Series - Assembly and Operation; Handlebar and Monitor Connection; Correct Exercise Posture; Manufacturer Service Information

STEP 7. a. ASSEMBLE HANDLEBAR ( 06 ) ONTO HANDLEBAR POST ( 05 ) FASTEN THE
T-KNOB ( 25 ) WITH M8 SMALL WASHER ( 32 ) ON IT ( 05 )
ASSEMBLE FOAM GRIP ( 17 ) AND HANDLEBAR END CAP ( 16 )
NOTE USE SOME SOAP WATER AS LUBRICANT WHILE FITTING FOAM GRIP.
b. CONNECTING WIRE (A)( 11 ) WITH MONITOR ( 08 ) THEN SLIDE THE
MONITOR INTO MOUNTING PLATE CAREFULLY
STEP 8. a. ATTACH HALF MOON BRACKET ( 39 ) HANDLEBAR ( 06 ) TO HANDLEBAR
POST ( 05 ) AND FIX WITH SCREW ( 38 ) T-KNOB ( 25 ) & WASHER ( 32 )
DO NOT OVERTIGHTEN THE SCREW & T-KNOB BEFORE THE HANDLEBAR
LOCATED IN DESIRED POSITION ( PLEASE REFER TO FIG. C )
( NOTE TO ADJUST ANGLE OF HANDLEBAR BY UN SCREWINGT KNOB
THEN TIGHTEN IT FIRMLY )
b. INSERT THE GRIP PULSE WIRE ( 36 ) INTO THE HANDLEBAR POST AND LET
IT THROUGH THE TOP OF MONITOR MOUNTING PLATE
c. CONNECTING WIRE (A)( 11 ) & GRIP PULSE WIRE ( 36 ) WITH MONITOR ( 08 ).
( PLEASE REFER TO FIG. D )
IF YOUR MODEL NO IS PEC - 2055 PLEASE DO d.
d. CONNECTING WIRE (A)( 11 ) & GRIP PULSE WIRE ( 36 ) & MONITOR CABLE
(A)( 40 ) WITH MONITOR ( 08 ) ( PLEASE REFER TO FIG. E )
e. SLIDE THE MONITOR INTO MOUNTING PLATE CAREFULLY
MANUFACTURER SERVICE
PROTEUS SPORTS INC.
"FOR CUSTOMER SERVICE
PLEASE CONTACT THE SALES
OUTLET, WHERE YOU PURCHASED
THIS EQUIPMENT, FOR CUSTOMER SERVICE"
CORRECT POSTURE FOR PEC-2035 SERIES
- 4 -
