" THE BATTERIES MUST BE REMOVED FROM THE APPLIANCE BEFORE IT IS
SCRAPPED AND THAT THEY ARE DISPOSED OF SAFELY ".
STEP 8 : CONNECT WIRE (A)( 10 ) AND WIRE (B)( 11 ), CONNECT MONITOR CABLE (A) &
MONITOR CABLE (B)( 39 & 39 ), THEN ATTACH HANDLEBAR POST ( 04 ) TO MAIN
FRAME ( 01 ), FIX WITH WASHERS ( 31 ) AND BOLTS ( 28 ). ( PLEASE REFER TO
FIG. D )
STEP 9 : ASSEMBLE FOAM GRIP ( 16 ) & END CAP ( 15 ) ONTO ONE SIDE OF HANDLEBAR
( 05 ), THEN ASSEMBLE HANDLEBAR ( 05 ) ONTO HANDLEBAR POST ( 04 ), FIX
WITH WASHER ( 32 ) AND T-KNOB ( 25 ), ASSEMBLE FOAM GRIP ( 16 ) AND END
CAP ( 15 ) ONTO ANOTHER SIDE OF HANDLEBAR ( 05 ).
NOTE : USE SOME SOAP WATER AS LUBRICANT WHILE FITTING FOAM GRIPS.
STEP 10 :
a. ATTACH HAND PULSE UPPER COVER ( 36 ) AND HAND PULSE BOTTOM COVER
( 37 ) TO HANDLEBAR ( 05 ), FIX WITH SCREWS ( 40 ). ( PLEASE REFER TO FIG.
C & FIG. G )
b. LEAD HAND PULSE SENSOR WIRE ( 36 ) FROM HOLE OF HANDLEBAR POST ( 04 ),
PULL IT OUT FROM MONITOR MOUNTING PLATE. ( PLEASE REFER TO FIG. H )
c. CONNECT MONITOR CABLE ( A ) ( 38 ), WIRE ( A ) ( 10 ) AND HAND PULSE
SENSOR WIRE ( 36 ) TO MONITOR ( 07 ). THEN ATTACH MONITOR ( 07 ) ONTO
MOUNTING PLATE OF HANDLEBAR POST ( 04 ) WITH SCREWS ( 35 ). ( PLEASE
REFERTO FIG. E )
NOW YOUR PEC-3350 PROGRAMMABLE MAGNETIC CYCLE HAS BEEN WELL ASSEMBLED.
- 4 -
MANUFACTURER SERVICE
PROTEUS SPORTS INC.
"FOR CUSTOMER SERVICE
PLEASE CONTACT THE SALES
OUTLET, WHERE YOU PURCHASED
THIS EQUIPMENT, FOR CUSTOMER SERVICE"
CORRECT POSTURE
