Proteus PEC-3320 - Parts List

PARTS LIST
KEY. Q'TY DESCRIPTION
01. 1 MAIN FRAME
02. 1 FRONT STABILIZER
2a. 1 REAR STABILIZER
03. 1 SEAT POST
04. 1 HANDLEBAR POST
05. 1 HANDLEBAR
06. 1 CRANK ASSEMBLY
07. 1 CYCLEMONITOR
*08. 1 TENSION CONTROL
*09. 1 TENSION CABLE
10. 1 WIRE ( A )
11. 1 WIRE ( B )
12. 1 SADDLE
13. 1 SEAT POST BOOT
14. 1 30*60 SLEEVE
15. 2 HANDLEBAR END CAP
16. 2 FOAM GRIP
17. 1 PEDAL ( R )
18. 1 PEDAL ( L )
19. 1 CHAIN COVER ( R )
20. 1 CHAIN COVER ( L )
21. 1 CHAIN COVER ( F )
22. 2 CRANK HOLE COVER
23. 2 WHEEL
24. 2 FOOT CAP
25. 1 T-KNOB
26. 1 KNOB
27. 4 M8 SOCKET BOLT x 70mm
28. 4 M8 SOCKET BOLT x 15mm
*29. 1 M5 SCREW x 25mm
30. 2 M5 SCREW x 15mm
31. 8 M8 WASHER
32. 1 M8 SMALL WASHER
33. 3 M8 SPRING WASHER
34. 3 M8 NYLON NUT
35. 4 M5 SCREW x 10mm
36. 2 HAND PULSE UPPER COVER W/ WIRE
37. 2 HAND PULSE LOWER COVER
38. 1 MONITOR CABLE ( A )
39. 1 MONITOR CABLE ( B )
40. 4 M3 SCREW x 15 mm
- 6 -
REMARK : " " MEANS USEING IN PEC-3300.PEC-3320.PEC-3380 ONLY.
