Proteus PEC-4650 - Parts List

- 4 -
PARTS LIST
KEY. Q'TY DESCRIPTION
1. 1 MAIN FRAME
2. 1 FRONT STABILIZER
3. 1 REAR STABILIZER
4. 1 SEAT POST
5. 1 HANDLEBAR POST
6. 1 HANDLEBAR
7R. 1 CRANK (R)
7L. 1 CRANK (L)
8. 1 CYCLEMONITOR
9. 1 MONITOR CABLE (A)
10. 1 MONITOR CABLE (B)
11. 1 CHAIN COVER (R-1)
12. 1 CHAIN COVER (L-1)
13. 1 CHAIN COVER (R-2)
14. 1 CHAIN COVER (L-2)
15. 1 30 * 60 SLEEVE
16. 2 HANDLEBAR END CAP
17. 2 FOAM GRIP
18. 1 PEDAL (R)
19. 1 PEDAL (L)
20. 1 SADDLE
21. 1 SEAT POST BOOT
22. 4 M5 SCREW
23. 2 WHEEL
24. 2 FOOT CAP
26. 1 KNOB W/ CLAMP
27. 2 M8 BOLT X 90mm
28. 10 M8 SOCKET BOLT X 20mm
29. 12 M8 WASHER
31. 3 M8 SPRING WASHER
32. 3 M8 NYLON NUT
33. 2 M8 DOME NUT
