Proteus TG-520 - Page 16

ASSEMBLY INSTRUCTIONS
- 14 -
M22
M12
M22
STEP. 16
Protective net (M22 )
have to go through the
Net holder-upper (M12).
STEP. 16-1
leave as base for turn it and don't tighten it.
Turn the Bolt (M74 ) not to the end,
STEP. 16-2
Put those bolt into machine,
don't tighten it (finger tight only).
M64
M87
M74
M74
M12
gap
M87
M64
