Proteus TG-520 - Parts List

PARTS LIST
NO. DESCRIPTION Q'TY
M01 Base frame 1
M02 Base cross beam 1
M03 Upright frame 1
M04 Top frame 1
M05 Seat support frame 1
M06 Leg curl 1
M07 Press arm frame 1
M08 Left press arm 1
M09 Right press arm 1
M10 Pad adjustable frame 1
M11 Guide tube 2
M12 Net holder -upper 1
M13 Pulley bracket 2
M14 Lat bar 1
M15 Steering knuckle arm 1
M16 Guide tube stopper 2
M17 T bar 1
M18 Foot plate 400 x 250 x3.0t 1
M19 Seat pad 1
M20 Back rest pad 1
M21 Pop pin 2
M22 Protective net 1
M23 Top cable 1
M24 Pec deck pulley bracket 2
M25 Net holder-lower 1
M26 Chain Ø5 x 3 1
M27 Bushing Ø24 x Ø12 x 12 2
M28 Mid cable 1
M29 Bushing Ø12 x Ø16 x 22 8
