PARTS LIST
- 20 -
NO. DESCRIPTION Q'TY
M61 Nylon ball SR20 x Ø8 2
M62 Rectangle and plug 30 x 60 x 1.5t 2
M63 Nylon nut M12 x 10.2 x 18 3
M64 Nylon nut M8 x 6.8 x 13 3
M65 Snubber 2
M66 Hex bolt M10 x 65 / 39 4
M67 Hex bolt M8 x 20 / 28 7
M68 Hex bolt M10 x 60 / 34 1
M69 Hex bolt M10 x 25 3
M70 Hex bolt M10 x 20 5
M71 Hex bolt M8 x 25 7
M72 Hex bolt M10 x 35 2
M73 Hex bolt M8 x 25 / 33 1
M74 Hex bolt M8 x 65 2
M75 Hex bolt M12 x 175 / 160 1
M76 Hex bolt M8 x 10 2
M77 Hex bolt M12 x 135 1
M78 Hex bolt M10 x 55 1
M79 Hex bolt M6 x 8 2
M80 Hex bolt Ø12 x 75 1
M81 Hex bolt M10 x 45 / 19 9
M82 Hex bolt M10 x 75 / 60 1
M83 Nylon nut M10 x 8.6 x 16 32
M84 Adjustable bolt Ø19 x 100 1
M85 Lock nut M10 2
M86 Washer Ø13.5 x Ø24 x 2.5t 6
M87 Washer Ø9 x Ø16 x 1.6t 10
M88 Washer Ø11 x Ø20 x 2.0t 58
M89 Hex bolt M10 x 135 2
M90 Lock nut M8 1
M91 Hex bolt M10 x 70 7
M92 Hex bolt M10 x 80 4
M93 Inner hexagonal bolt M8 x 20 2
M94 Press arm breaket 1
M60 Stopper M10 2
