PT3378-WWVB Manual
A10: Indoor Temperature
A11: Weather Forecasting
Part B – Side button and power
B1: ” touch field
B2: ”button
B3: ” button
B4: “▲” button
B5: “▼” button
B6: ” button
B7: ”button
B8: “
MEM
” button
B9: Alarm on/off switch
B10: Power supply socket
B11: USB charger output socket
B12: Battery slots.
Part C –Wireless Remote Sensor:
C1: LCD display – Temperature
C2: LCD display – Humidity
C3: Signal transmission indicator light
C4: “°C/°F” button
C5: “TX” button (press this button if there is no data displayed on your weather station)
C6: “CHANNEL 1 / 2 / 3” switch
C7: Battery slots
