22
GB
Sword saw
SSP 200 EB
Table of contents
1 Technical data ........................... 22
2 Symbols ................................... 23
3 Operating elements .................... 23
4 Applications .............................. 23
4.1 Description ................................ 23
4.2 Tool properties ........................... 24
5 Safety instructions ..................... 24
5.1 General safety instructions .......... 24
5.2 Safety warnings for the
SSP 200 EB sword saw ............... 24
5.3 Residual safety risks ................... 28
5.4 Noise / Vibration Information ........ 28
6 Transport and delivery ................ 28
6.1 Storage .................................... 28
7 Adjustment ............................... 28
7.1 Tilting the guide bar lengthwise ... 28
7.2 Cutting angle adjustment ............ 29
7.3 Motor electronics ....................... 29
8 Preparation for use ..................... 29
8.1 Mounting the chain ..................... 29
8.2 Filling the oil reservoir ................ 29
8.3 Electrical connection ................... 30
9 Operation ................................. 30
9.1 Switching on and off ................... 30
9.2 Controlling chain and guide bar
lubrication ................................. 30
9.3 Cut indicator ............................. 30
9.4 Guide ruler ................................ 30
9.5 Exhaust .................................... 30
10 Using accessories ....................... 30
10.1 The PROTOOL guide system ........ 31
10.2 Assembling the guide rail
(GRP 800/1400/3000-2) ............. 31
10.3 Assembling the angle guide
(GRP-AG-2) ............................... 31
10.4 Assembling the connector
(CN-GRP) .................................. 31
10.5 Assembling the quick clamp
(GRP-Rapid/L) ........................... 31
11 Care and maintenance ................ 31
11.1 Chain tension ............................ 31
11.2 Maintaining and sharpening
the chain .................................. 32
11.3 Lubricating the chain .................. 32
11.4 Maintaining the guide bar ............ 32
11.5 Maintaining the chain sprocket ..... 32
11.6 Replacing the chain
and guide bar ............................ 32
11.7 Replacing the chain sprocket ....... 33
11.8 Lubrication and cleaning ............. 33
11.9 Replacing the carbon brushes ...... 33
12 Environmental Protection /
Disposal.................................... 33
13 Warranty .................................. 33
14 Declaration of Conformity ............ 34
15 Service ..................................... 34
15.1 Troubleshooting ......................... 34
1 Technical data
System voltage 230 V ~
Network frequency 50 / 60 Hz
Rated input 1600 W
Movable supply H07RN-F
Circuit breaker 15 – 16 A
current protection
Pre-selection of number of rotations •
Constant electronics •
Electric safety brake •
Restricted circuit power •
Speed of sprocket wheel
at the electronics set
at the level of: 2200 – 4600 min
–1
Maximum chain speed 10.6 m/s
Mutual inclination
of the guide reglet
0° – 60°
Weight (tool included) 6.5 kg
Depth of the cut
[Guide reglet 8″ (20 cm)]
at 0° 200 mm
at 15° 190 mm
at 30° 170 mm
at 45° 140 mm
at 60° 100 mm
Protection class II /
Automatic lubrication
of the guide reglet
•
Oil tank volume ~ 240 ml
