6
Storage Temperature :
-40
°
C ~ 60
°
C (-40
°
F ~ 140
°
F)
Power Consumption : Approx. 6 mA
Battery Type : 9V
Battery Life : 50 hours ( for 300mA-hrs battery)
Averaging Period for Wind Speed Measurement
m/s : 0.6 sec.(approx.)
ft/min : 1.2 sec.(approx.)
knots : 1.2 sec.(approx.)
km/hr : 2.2 sec.(approx.)
Dimension : Meter 3.46"x 6.61"x 1.03" (88x 168 x 26.2mm)
Vane 2.60"x 5.22"x 1.15" (66x 132 x 29.2mm)
Weight : 12.34oz / 350g. (battery included)
Accessories : Carrying case x 1
Users manual x 1
9V Battery x 1
V. Battery Replacement
When the low battery symbol is displayed on LCD, follow the following
procedures to replace the battery.
A. Turn off the anemometer by pushing the On/Off button.
B. Remove the screw of the battery compartment cover and remove the
battery compartment cover.
C. Replace the old 9V battery with a new 9V battery.
D. Replace the battery compartment cover and fasten the screw.
