Proview UK513 - F. SPARE PARTS LIST (Continued); Diodes, Transistors, and Crystals; Fuses, Connectors, and Cables

UK513 13 / 26
36 506-0AI-18CE AIC 1084CE 1.8V T0252 SMD. EA 1 I1
,
37 506-0AI-C1084 SMD REG.AIC1084CM 3.3V 5A. EA 1 I2
,
38 506-10E-8050I
Q
MXIC MX10E8050I
Q
C PLCC44 EA 1 MCU
,
39 506-524-LC21-S MEMORY IC 24LC21 SMD .ST EA 1 U2,
40 506-5NM-24C16 24C16 SO8 MEMORY IC SMD. EA 1 U4,
41
506-MST-
TSU16AK
SMD MST TSU16AK LVDS+RSDS VGA
ONLY
EA 1 U3,
42 518-02N-3904 TR NPN PMBS3904 40V 100mA EA 6
Q
1
,Q
2
,Q
7
,Q
4
,Q
6
,Q
203
,
43 518-02N-3906 TR PNP PMBS3906 40V 100mA EA 1
Q
204
,
44 518-1CE-9435 MOSFET CE9435A S08. EA 1 U1
,
45 520-005-G317-F LED 3D2P EA 1 D1
,
46 528-2BA-T54C SMD DIODE BAT54C SOT23. EA 1 D1
,
47 528-R1N-4148 DIODE 1N4148 SOT-34 SMD. EA 1 D10,
48 531-110-49US 11.0592MHZ HC 49US CRYSTAL. EA 1 Y1,
49 531-143-49US-2 KTS
Q
YSTAL 14.318MHZ. 20PF EA 1 X1,
50 558-352-5000 SMD FUSE 1206 24V 5A. EA 1 F1,
51 600-151-5100B POWER CORD 3P BALCK1.5M EA 1
52 610-151-28G9-A VGA Pi
g
tail 1.5M WITHOUT AUDIO EA 1
53 630-008-1009 BASE 8P.180° EA 1 C0N1
,
54 630-008-C001 JST 1.5mm HEADER ZR S8B-ZR. EA 1 J1
,
55 630-026-S2006 BASE 2.0 26P /JWTA2006 EA 1 JP1
,
56 630-028-1008S BASE 28PIN EA 1 CN2
,
57 631-020-J572-2 20PIN 1.25PITCH->26PIN 2.0 PITCH EA 1
58 631-C08-8M713 M713 8P2.0-1.5 290 +CORE EA 1
59 640-003-0005 SHRINK TUBE 5mm Φ3mm EA 1
60 701-150-V002 15"NEC PANEL B/L EA 1
61 705-550-502V
15"NEC PANEL(PTS B/L) Response
time25
EA 1
62 707-250-3001-Z
15"NEC PANEL BACKBRIGHT BOARD
PMMA VH5-000
EA 1
63 780-103-3000CA BEAD FCM1608K-300T07 HILISIN EA 3 FB4,FB5,FB6,
64 780-104-600C30
SMD BEAD 0805 60Ω/100MHz 3A
HILISIN
EA 9
FB1,FB3,FB7,FB8,FB9,FB10,FB11,FB12,L
1
65 860-ALZ-M513 M513 POWER 3in1 AU 2L EA 1
66 899-01F-M513-A
MSTAR TSU16AK LVDS PIGTALL
REV:A
EA 1
67 899-400-PZ456
PZ-456 KEY BOARD WITH GREEN
LED
EA 1
