B. SPECIFICATIONS
Panel General Specification
Panel Model NEC SVA150XG03TB
Screen Diagonal 15” TFT
Active Display Area 304.1mm (H) x 228.1mm (V)
Pixel Pitch 0.297(H) x 0.297(V) mm
Number of Colors 262K colors
View Angle
Horizontal
Vertical
+/-60 degree
+40/-60 degree Typical
Luminance of White 250cd/m²(Typical)
Contrast Ratio (Typical) 400:1
Maximum Resolution 1024 x 768 @ 75Hz
Recommend Resolution 1024 x 768 @ 75Hz
Synchronization Range
Horizontal
Vertical
30 – 60 KHz
60– 75 Hz
Pixel Rate 80 MHz
User Control 5 Key Switch
OSD Function Brightness, Contrast, H-position, V-position, H-size,
Phase, Reset, Color selection (R, G, B, cool, warm), OSD ,
Language, Exit, Auto
Power Source 90 – 264 Vac 60 / 50 Hz
Power Consumption 36 W (max.)
Connection Type 15 Pin D-Sub Type;
Input Signal
Video
Sync.
Analog R.G.B. , 0.7Vp-p / 75 Ohm
TTL level,positive or negative polarity
Color Temperature Cool / Warm / user mode
Dimension (WxHxD) 344..4 x 332.7 x 166.0 (mm)
Monitor Weight 2.7 kg
Base Operation
Tilt
-5 / + 15 degree
Power Saving
ON
Sleep mode
OFF
＜ 36W
＜ 3W
＜ 3W
Signal Connector Pin Assignment
D-SUB Pin
1.Red Video 6. Red Ground 11. GND
2.Green Video 7. Green Ground 12. SDA For DDC2B
3.Blue Video 8. Blue Ground 13. H-sync.
4.GND 9. VCC +5V 14. V-sync-DDC1
5.Self Test 10. Sync. GND 15. SCL For DDC2B
Sound Output No Audio
