F. SPARE PARTS LIST
Main Board/ Control Board
No. Parts Number Parts Description Unit Q'ty Location
1 281-031-39004 SMD 390ohm 0603 +-1% EA 1 R40
,
2 281-031-75R04 RES 75 1% 1/10W 0603 SMD. EA 3 R29
,
R32
,
R36
,
3 281-035-0R04 RES 0ohm 5% 1/10W 0603 SMD. EA 2 R3
,
R39
,
4 281-035-1004 RES 10ohm 5% 1/10W 0603 SMD. EA 1 R41
,
5 281-035-1014 RES 100ohm 5% 1/10W 0603 SMD EA 4 R66
,
R67
,
R213
,
R4
,
6 281-035-1024 RES 1K 5% 1/10W 0603 SMD. EA 4 R5
,
R14
,
R69
,
R70
,
7 281-035-1034 RES 10K 5% 1/10W 0603 SMD. EA 11
R21,R23,R42,R64,R65,R68,R72,R19,R20,
R207
,
R47
,
8 281-035-1044 RES 100K 5% 1/10W 0603 SMD. EA 1 R6,
9 281-035-1824 RES 1.8K 5% 1/10W 0603 SMD. EA 2 R17,R22,
10 281-035-2004 RES 20 5% 1/10W 0603 SMD. EA 3 R28,R31,R35,
11 281-035-2224 RES 2.2K 5% 1/10W 0603 SMD. EA 2 R24
,
R204
,
12 281-035-2234 RES 22K 5% 1/10W 0603 SMD. EA 1 R13
,
13 281-035-3304 RES 33ohm 5% 1/10W 0603 SMD. EA 4 R211
,
R212
,
R26
,
R27
,
14 281-035-3314 RES 330ohm 1/10W 0603 SMD. EA 2 R62
,
R63
,
15 281-035-3324 RES 3.3K 5% 1/10W 0603 SMD. EA 1 R208
,
16 281-035-3334 RES 33K 5% 1/10W 0603 SMD. EA 2 R206
,
R1
,
17 281-035-4704 RES 47ohm 5% 1/10W 0603 SMD. EA 7 R30
,
R34
,
R37
,
R43
,
R44
,
R45
,
R46
,
18 281-035-4714 RES 470ohm 5% 1/10W 0603 SMD. EA 1 R33
,
19 281-035-4724 RES 4.7K 5% 1/10W 0603 SMD. EA 2 R2
,
R16
,
20 281-035-8224 RES 8.2K 5% 1/10W 0603 SMD. EA 1 R74
,
21 281-075-0R04 RES 0ohm 5% 1/4W 1206 SMD EA 2 D11
,
D12
,
22 282-103-2454 RES-NET 10Kohm 5% SMD 8P4R. EA 6 RN12,RN13,RN14,RN15
,
RN6
,
RN5
,
23 282-220-2454 22X4 +-5% 1/10W SMD 8P4R EA 2 RN10
,
RN11
,
24 285-056-B160C SMD VARISTOR SIZE 0603 5.6V 30PF EA 8 D4
,
D7
,
D9
,
D8
,
D101
,
D3
,
D5
,
D6
,
25
330-100-16253-
W
EC 10uF 16V 105°C M TP MI 4*5 EA 7 TC7
,
TC9
,
TC8
,
TC10
,
TC11
,
TC12
,
TC14
,
26
330-221-16203-
W1
EC.220uF/16V 105°C Φ6*11 EA 3 TC3
,
TC4
,
TC6
,
27
330-470-16273-
W
EC.H7mm 105°C 47uF/16V EA 2 TC1,TC2,
28
381-102-
035054H
NPO 1000P/50V +-5% 0603 SMD FOR
RoHS
EA 1 C23,
29
381-220-
032554H
SMD CC 22pF 25V NPO 0603. FOR
RoHS
EA 4 C49
,
C52
,
C66
,
C68
,
30
385-104-
032584H
Y5V 0.1u/25V +80%-20% 0603FOR
RoHS
EA 35
C1,C2,C4,C6,C7,C11,C12,C13,C14,C15,C17
,C32,C33,C34,C35,C36,C37,C38,C39,C40,
C41,C42,C43,C44,C45,C46,C47,C48,C53,
C54
,
C56
,
C59
,
C3
,
C64
,
C65
,
31
385-105-
031684H
Y5V 1uF/16V +80-20% 0603. FOR
RoHS
EA 6 C5
,
D31
,
D32
,
D33
,
D34
,
D35
,
32
385-473-
032584H
Y5V 0.047u/25V +80%-20% 0603FOR
RoHS
EA 6 C19
,
C21
,
C22
,
C25
,
C26
,
C31
,
33 401-270-0205 TACT SW 2P 6*3.5 H 5.0 180
g
EA 5 S1
,
S2
,
S3
,
S4
,
S5
,
34 481-LCC-0440 SOCKET 44PIN PLCC. EA 1 U5
,
35 483-302-2388 2.5P 254FH15 1S H8.50mm EA 1 CN1
,
