Proview UK513 - D. ADJUSTMENT PROCEDURE; Power and Saving Mode Checks; Factory, Auto Mode, and OSD Settings

UK513 7 / 26
D. ADJUSTMENT PROCEDURE
ITEM
P
rogram Menu.
﹟
Test Meter
﹡
Test Point
﹫
Pattern
Operation
Check
Value
A
Power supply
Check
﹟
Digital Voltmeter
﹡CN2
﹫
Crosshatch Pattern
(1280x768, 60Hz)
1. Plug power cable into the LCD monitor directly.
2. Make sure the voltage of the power plug (CN2)
on the Power Board to the value shown at right.
220Vac
±0.2V
B
Power Saving
Check
﹟
Wattmeter
﹟
PC or Pattern
generator
﹫
Crosshatch Pattern
(1280x768, 60Hz)
1. Unplug the signal cable into the monitor.
2. Turn the power switch of the monitor
ON
.
3. Check monitor power indicator light up blue
flashing every other second.
4. Make sure the wattmeter value shown at right.
5.
OSD
will be display “
NO SIGNAL
” Picture.
‹ 3W
C
Into Factory
mode
﹟
PC or Pattern
generator
﹫
Crosshatch Pattern
(1280x768, 60Hz)
1. Hold
Down
key,then turn the power switch of the
monitor
OFF
.
2. Hold Up key,then turn the power switch of the
monitor
ON
.
3. You can enter factory adjustment mode.
D
Auto mode
Check
﹟
PC or Pattern
generator
﹫
Crosshatch Pattern
(1280x768, 60Hz)
1.Press and release the Auto key to adjust display
mode to its utmost performance according to
VGA
setting.
E
White
Balance
Adjust
﹟
PC or Pattern
generator
﹫
White Pattern
(1280x768, 60Hz)
1. Move the
OSD
to the
COLOR
mode
(
AUTO COLOR).
2. set color is Cool using the
OSD
,Check the value
shown at right.
Y = 200±20cd/m^2 x = 0.283±0.02 y = 0.297±0.02
3. set color is Warm using the
OSD
,Check the value
shown at right.
Y = 200±20cd/m^2 x = 0.313±0.02 y = 0.329±0.02
F
OSD
Language
Setting
﹟
PC or Pattern
generator
1. Move the OSD to the OSD setting mode
2. Move the
OSD
to the
LANGUAGE
mode
.
3. You can choose one of the language you need.
