Proxim ORiNOCO AP-9100 Hardware Installation Guide

Hardware Specifications
ORiNOCO
®
802.11n & 802.11ac Access Points - Hardware Installation Guide 33
3.1.1 Antenna Specifications
• Omni Directional Antenna (Supplied with the Product)
• Range Extender Antenna (REA) (Not Supplied with the product)
3.1.1.1 Omni Directional Antenna Specifications
Feature Electrical Specifications
Frequency Range 2400 MHz - 2500 MHz 4900 MHz – 5875 MHz
Peak Gain 2.5 dBi 5 dBi
Average Gain 1.5 dBi 3 dBi
VSWR 2.0 : 1 Max
Polarization Linear, Vertical
HPBW/Horizontal 360
o
360
o
HPBW/Vertical 50
o
25
o
Power Handling 2W (cw)
Impedence 50 Ohms
Connector RP SMA Plug
Feature Environmental and Mechanical Specification
Temperature -10°C to +55°C
Humidity 95% @55°C
Radome color White
Radome material ABS, UV resistant
Weight 21 g
Dimensions 19 x 39 x 127 mm
Power Handling 2W (cw)
