Proxim ORiNOCO AP-9100 Hardware Installation Guide

Hardware Specifications
ORiNOCO
®
802.11n & 802.11ac Access Points - Hardware Installation Guide 37
3.2 ORiNOCO
®
AP-8100
Category Specification
Power
Requirements
Power Adapter: 12V/1.25A
Power over Ethernet (PoE) (optional): 48V / Any 802.3af compliant Gigabit PoE
Radio Module Dual Radio Access Point, 2x2 MIMO per radio
Radio1: IEEE 802.11a/n
Radio2: IEEE 802.11b/g/n
Refer Device Operational Modes.
Wireless
Protocol
802.11a/n
802.11a
802.11g
802.11b/g/n
Frequency 5.150 - 5.850 GHz*
2.4 - 2.483 GHz
* Subject to Individual Country Regulations
Channel
bandwidth
20MHz and 40MHz for 802.11n
20MHz for 802.11a/b/g
Modulation • BPSK, QPSK, 16-QAM and 64-QAM:
– With data rates of 6.5 Mbps -300 Mbps for 802.11n
– With data rates of 6 Mbps - 54 Mbps for 802.11a and 802.11g
• DSSS, CCK: With data rates of 1 Mbps -11 Mbps for 802.11b
Device Interface Ethernet: Auto-sensing 10/100/1000BASE-T Ethernet
LED Indicators Refer Step 4: View LEDs
Antennas 4 Modular High Efficiency built-in PIFA Antennas with a peak gain of:
– 3dBi for 2.4 GHz frequency.
– 4dBi for 5 GHz frequency.
Network
Architecture
Type
Infrastructure
: The operational mode ‘g/n’ is backward compatible to mode ‘b’.

Proxim ORiNOCO AP-9100 Specifications

General

Brand	Proxim
Model	ORiNOCO AP-9100
Category	Wireless Access Point
Language	English
