Proxim ORiNOCO AP-9100 Hardware Installation Guide

Hardware Specifications
ORiNOCO
®
802.11n & 802.11ac Access Points - Hardware Installation Guide 35
HPBW/Vertical 35
o
- 50
o
17
o
- 27
o
Power Handling 2W (cw)
Impedence 50 Ohms
Cable ULA100-3F, White, 1.5 m
Connector RP SMA Plug x 3 (Quick Connector)
Lightning Protection N/A
* Exclusive of cable loss 2.5 dB @ 2.4 GHz and 5 dB @ 5.5 GHz
Feature Environmental and Mechanical Specification
Temperature -10°C to +55°C
Humidity 95% @55°C
Radome color White
Radome material ABS, UV resistant
Weight 0.2 g
Dimensions 76.6 x 185 mm
Mounting Kit Desktop Mount and Ceiling mount
Feature Electrical Specifications
