-10-
Turn the clamping mechanism of the device 1
(fig. 2) to the left by 90° up to the limit stop and
push in the insert.
Then turnthe clamping mechanism (1) 90° to
the right again. The insert is now locked.
Attach suitable sandpaper (self-adhesive), as
shown in fig. 3.
Switch on the device switch and hold the pen
grinder like aballpoint pen. The grinding move-
ment (the stroke) goes from top to bottom and
vice versa.
Simply remove and replace wornsandpaper.
Applications for your PS 13:
Some typical applications for the PS 13 are
shown in the figures on the fold-out page.
Important:
It is best to work with slight contact pressure,
so that the grind insert can vibrate slightly.This
makes the device as efficient as possible.
Careand maintenance
Apart from occasional cleaning, the device re-
quires no special maintenance. If you observe
the instructions in these operating instructions,
the device will provide you with reliable, safe
and long-lasting quality service.
We reserve the right to make changes in keep-
ing with technical progress.
Disposal:
Please do not dispose of the device in domestic
waste! The device contains valuable substances
that can be recycled. If you have any questions
about this, please contact your local waste
management enterprise or other corresponding
municipal facilities.
Warranty provisions
All PROXXON products arethoroughly inspect-
ed after production. Should adefect occur nev-
ertheless, please contact the dealer from whom
you purchased the product. Only the dealer is
responsible for handling all legal warranty
claims which refer exclusively to material and
manufacturer error.
Improper use, such as capacity overload, dam-
age due to outside influences and normal wear
areexcluded from the warranty.
Youwill find further notes for each country re-
garding "Service and SpareParts Management"
at www.proxxon.com.
EC declaration of conformity
Name and address of the manufacturer:
PROXXON S.A.
6-10, Härebierg
L-6868 Wecker
Product designation: PS 13
Article No.: 28594
In sole responsibility,wedeclarethat this prod-
uct conforms to the following directives and
normative documents:
EU EMC Directive 2014/30/EU
DIN EN 55014-1 /05.2012
DIN EN 55014-2 /06.2009
DIN EN 61000-3-2 /03.2010
DIN EN 61000-3-3 /06.2009
EU Machinery Directive 2006/42/EC
DIN EN 60745-1 /01.2010
DIN EN 60745-2-4 /11.2012
Date: 12.09.2017
Dipl.-Ing. JörgWagner
PROXXON S.A.
Machine Safety Department
The CE document authorized agent is identical
with the signatory.
