PTZOptics Move 4K - Technical Specifications (Continued); Communication Interface Details; Physical Parameters

9
™
Communication Interface
▪ 1x 8-pin Mini DIN RS232 Input, Max distance: 98.5ft / 30m,
Protocol: VISCA / Pelco-D / Pelco-P
▪ 1x 8-pin Mini DIN RS232 Output, Max distance: 98.5ft / 30m,
Protocol: VISCA / Pelco-D / Pelco-P
▪ 1x 2-pin Phoenix port RS485 Input / Output, Max distance:
3,937ft / 1200m, Protocol: VISCA / Pelco-D / Pelco-P
IR
4x IR Addresses, Max distance 30ft / 9m
Power Jack
JEITA Type (DC IN 12V)
Physical Parameter
Input Voltage DC 12V / PoE+(802.3af)
Current Consumption Max 2A
Operating Temperature 14°F ~ 104°F (-10°C ~ 40°C)
Storage Temperature -40°F ~ 140°F (-40°C ~ 60°C)
Humidity Range 10% - 80%
Power Consumption Max 18W
Size in. (W x D x H) (12X) 5.57” W x 5.94” (6.65 including SDI) D x 6.93” (7.91” with tilt
up) H
(20X) 5.57” W x 5.94” (6.65 including SDI) D x 6.93” (7.91”
with tilt up) H
(30X) 6.69” W x 7.12” (7.75 with SDI) D x 8.98” (10.5” with tilt
up) H
Size mm. (W x D x H) (12X) 141.5 W x 151 (169 including SDI) D x 176 (201 with
tilt up) H mm
(20X) 141.5 W x 151 (169 including SDI) D x 176 (201 with
tilt up) H mm
(30X) 170 W x 181 (196.85 including SDI) D x 228 (266.7
with tilt up) H mm
Camera Weight (12X) 3.25 lbs | 1.47 kg
(20X) 3.25 lbs | 1.47 kg
(30X) 4.41 lbs | 2.0 kg
