HDMI Output: Encoding Settings
▪ Video Format: Adjusts resolution and frame rate. 1080p60, 1080p50, 1080p30, 720p60,
720p50
Video: Encoding Settings
▪ Refresh Rate: Frequency adjustment for displays. Select the refresh rate for your region.
Ŝ Options include: 50Hz, 60Hz
▪ Encode Protocol: The Encoding Prole denes the compression method and color reproduc-
tion of the IP Stream.
Ŝ Options include: Baselin, Main, High
▪ Video Template: Select O, High, Medium, Low, NDI|HX3: H.264, 1080@50, NDI|HX3: H.264,
1080@60, NDI|HX3: H.265, 1080@50, NDI|HX3: H.265, 1080@60
IP Video Stream 1 & 2: Encoding Settings
▪ Encoding Protocol: Dene the compression method for the stream.
Options include: H264, H265, MJPEG
▪ Resolution: Dene the resolution of the stream.
Ŝ Stream 1 options include: 1920x1080, 1280x720, 1024x576, 960x540, 630x480,
640x360
Ŝ Stream 2 option includes: 720x408, 640x480, 640x360, 480x320, & 320x240
▪ Bitrate (kbps): Dene the bit rate of the stream in kilobits. The higher the value, the higher
the video quality at the cost of higher bandwidth.
Ŝ Stream 1 Range: 32 ~ 102400kbps
Ŝ Stream 2 Range:32 ~ 20480kbps
▪ Frame Rate: Dene the Frame Rate of the stream.
Ŝ Range: 1 ~ 60
▪ I Key Frame Interval: Dene the I-Key Frame Interval of the stream.
Ŝ Options include: 1 ~ 1200
▪ Bit Rate Control: Select whether the Bit Rate uctuates (VBR) or is static (CBR).
Ŝ Options include: CBR, VBR
▪ Audio Encoding Settings
▪ Enable Audio: Select whether Audio is included in the applicable video outputs.
Ŝ Options include: On, O
▪ Audio Encoding Protocol: ACC
▪ Sample Rate (kbps): Dene the number of samples per second the audio utilizes.
Ŝ Options include: 32
▪ Bitrate (kbps): Dene the number of bits per second the audio utilizes in kilobits
Ŝ Options include: 96, 128
▪ Input Volume: Dene the Input Volume of the Audio Input.
Ŝ Range: 0db ~ 30db
▪ ADTS Options: Select whether Audio Data includes timestamps. On or O.
