11
3.2 Mounting the Puck Keysafe on a door frame
attention
Mounting should preferably be performed by a qualified installer.
To mount the Puck Keysafe on a door frame, do the following:
1. Open the Puck Keysafe. The code is factory preset to 0000.
• Using the number wheels enter the code '0000'.
• Turn the lid anti-clockwise and then pull it toward you.
2. Screw the key cabinet onto the mounting bracket.
Use the three bolts and the hex nuts.
Figure 12. Screw the key cabinet onto the mounting bracket
