2.1 Fixings
Figure 2. Safe fixing
Figure 3. Fixing mounting bracket
1. Hexagon bolt M8 x 40 mm (3x)
2. Wall Anchor (3x)
3. Hex nut M6 (3x) (optional)
4. Wood screw (4.5 x 30 mm) (optional)
5. Coach bolt M6 x 25 mm (3x) (optional)
2.2 Operating elements
Figure 4. Operating elements
1. Figure Wheels
2. Code setting slider
1 2
1
2
4 53
