Puck KEYSAFE - Page 8

8
User and assembly manual
4. Mark the holes.
Figure 6. Mark the holes
attention
The holes cannot be drilled into the joints.
5. Drill three 12 mm holes 85 mm deep.
Figure 7. Drill the holes
6. Insert the wall anchors.
Figure 8. Insert the wall anchors
