#2300 PARTS LIST
#2300 PARTS LIST
ITEM DESCRIPTION PART NO. QTY. MATERIAL
A FIFTH WHEEL PLATE ASSEMBLY 2901 1
B ROCKER ARM 2302 1 (See assembly components below in hardware kit)
C TURNTABLE CAM ARM 2303 1
C4 CAM ARM SHAFT WEAR PLATES 44120003 2
D ROLLER ASSEMBLY 2304 1
D1 ROLLER SLOTTED NUT 98150121 1 1”-14 SLOTTED NUT,
D2 ROLLER COTTER PIN 98410567 1 1/4” X 2” COTTER PIN
E TURNTABLE WAY TUBES 23060001 2
F
CAM ARM STOP ASSEMBLY
2308 1
F1 THREADED STOP ASSEMBLY 440501 1
F2 THREADED STOP HEX JAM NUT 98150141 1 5/8”-11 HEX JAM NUT
F3 THREADED STOP BOLT 98010232 1 5/8”-11 X 3.5” HHCS GRD 5
G HITCH BASE 2307 1
H WAY TUBE BRACKET ASSEMBLY 2305 1
HARDWARE KIT
B1 ROCKER ARM CLEVIS PIN 98410111 2 #3 COTTER PIN
B2 #3 PIN CLIP 98410127 2 1-2” X 2” CLEVIS PIN
B3 ROCKER ARM SPRING 35100001 1 16 GA SPRING STEEL
B4 ROCKER ARM SPRING FLAT WASHER 98250160 1 5/16” ZINC FLAT WASHER
B5 ROCKER ARM SPRING LOCK WASHER 98200159 1 5/16” ZINC SPLIT LOCK WASHER
B6 ROCKER ARM SPRING BOLT 98010242 1 5/16”-18 X 3/4” HHCS GRD 5
C1 ROCKER ARM PIVOT BOLT 98010147 1 3/4” -10 X 7” GRD 5
C2 PIVOT BOLT HEX NUT 98150131 1 3/4” - 10 ZINC HEX NUT
C3 PIVOT BOLT LOCK WASHER 98200124 1 3/4” ZINC PLATED SPLIT LOCK WASHER
E1
WAY TUBE BOLT
98050130 4 5/8”-11 X 8” CARRIAGE BOLT GRD 5
G2 WAY TUBE HOLDER BOLT 98010177 2 1/2”-13 X 1-1/4” HHCS GRD 5
G3 1/2” FLAT WASHER 98250145 10 1/2” FLAT WASHER
G4 5/8” FLANGE NUT 98150200 5 5/8”-11 SERRATED FLANGE NUT
G5 BASE RAIL FOOT BOLT 98010191 8 1/2”-13 X 4” HHCS GRD 5
G6 1/2” FLANGE NUT 98150201 10 1/2”-13 ZINC SERRATED FLANGE NUT
G7 HITCH PIN 27090001 4 1/2” ROUND
G8 #9 PIN CLIP 98410143 4 #9 COTTER PIN
G9
BASE FOOT ASSEMBLY 291101 4
BASE RAIL KIT
BASE RAILS ARE DIFFERENT FOR EACH APPLICATION AND ARE SOLD SEPARATELY. CALL (800) 443-2307 FOR MORE INFORMATION.
