#2900 PARTS LIST
#2900 PARTS LIST
ITEM DESCRIPTION PART NO. QTY. MATERIAL
A FIFTH WHEEL PLATE ASSEMBLY 2901 1
B ROCKER ARM 3302 1
C TURNTABLE CAM ARM 2903 1
C2 ROLLER 2904 1 ROLLER ASSEMBLY
C5 PLASTIC WEAR PLATE KIT 2910 1 MOLDED PLASTIC WEAR PLATES
D TURNTABLE WAY TUBES 2906 2
E CAM ARM STOP ASSEMBLY 2705 1
E1 STOP ASSEMBLY BOLT 98010219 1 5/8”-11 X 2-1/2” TAP BOLT GRD 5
E2 STOP ASSEMBLY JAM NUT 98150141 1 5/8”-11 HEX JAM NUT
E3 THREADED STOP ASSEMBLY 4405 1
F HITCH BASE 2907 1
HARDWARE KIT
B1 #3 PIN CLIP 98410127 2 #3 COTTER PIN
B2 ROCKER ARM CLEVIS PIN 98410111 2 1-2” X 2” CLEVIS PIN
B3 ROCKER ARM SPRING 35100001 1 16 GA SPRING STEEL
B4 ROCKER ARM SPRING FLAT WASHER 98250160 1 5/16” ZINC FLAT WASHER
B5 ROCKER ARM SPRING LOCK WASHER 98200159 1 5/16” ZINC SPLIT LOCK WASHER
B6 ROCKER ARM SPRING BOLT 98010244 1 5/16”-18 X 1” HHCS GRD 5
C1 ROCKER ARM PIVOT BOLT 98010147 1 3/4” -10 X 7” GRD 5
C3 PIVOT BOLT HEX NUT 98150131 1 3/4” - 10 ZINC HEX NUT
C4 PIVOT BOLT LOCK WASHER 98200124 1 3/4” ZINC PLATED SPLIT LOCK WASHER
D1 WAY TUBE BOLT 98050113 4 1/2”-13 X 3-1/2” HHCS GRD. 5 CARRIAGE BOLT
D2 STOP BRACKET BRACE 27050001 1
F1 BASE BOLT 98010191 8 1/2”-13 X 4” HHCS GRD 5
F2 BASE FLAT WASHER 98250145 8 1/2” ZINC FLAT WASHER
F3 HITCH PIN 27090001 4 1/2” ROUND
F4 #9 PIN CLIP 98410143 4 #9 COTTER PIN
F5 BASE FOOT ASSEMBLY 291101 4
G 1/2” FLANGE NUT 98150201 12 1/2”-13 ZINC SERRATED FLANGE NUT
BASE RAIL KIT
BASE RAILS ARE DIFFERENT FOR EACH APPLICATION AND ARE SOLD SEPARATELY. CALL (800) 443-2307 FOR MORE INFORMATION.
