Page 5
BASE RAIL FOOT ASSEMBLY
5. To minimize any forward and aft movement when towing, secure the feet as far apart, fore-to-aft, as the slot opening
on the base rail will allow. If you still experience movement, consider loosening the base rail fasteners and tapping the
base rails toward each other to achieve optimal positioning.
6. Torque the bolts to 75 ft. pounds.
7. An aftermarket, ½” Locking Hitch Pin, may be used in place of one or more of the standard Hitch Pin and Clips to
prevent theft.
BASE RAIL FOOT ASSEMBLIES — EXPLODED VIEW
#2911 base rail feet
hitch pin
# 9 pin clip
22”
