PullRite SuperLite 2400 - #2400 Parts List; Torque Table

Page 9
#2400 PARTS LIST
Item Description Part No. Qty. Description
A KING PIN ADAPTER 2403 1
B COUPLER TUBE ASSEMBLY 2402 1
C HITCH BASE 2401 1
D RELEASE HANDLE 2405 1
ADAPTER PLATE HARDWARE KIT -- 240302
A1 ADAPTER PLATE BOLT 98010203 2 1/2”-13 X 5-1/2” HHCS GRD 5
A2 ADAPTER BOLT REINFORCEMENT TUBE 24030201 1 0.75 X 0.531 TUBE
A3 FLAT WASHER 98250147 2 1/2” FLAT WASHER
A4 1/2” FLANGE NUT 98150201 2 1/2”-13 SERRATED FLANGE NUT
A5 3/8” FLANGE NUT 98150168 4 3/8”-16 FLANGE NUT
A6 ADAPTER PLATE SET SCREWS 98010222 4 3/8”-16 X 1.25” BOLT
LATCH PIN ASSEMBLY
B1 LATCH HANDLE 240205 1 HANDLE AND SPRING
B2 LATCH PIN HOUSING COVER 24020601 1
B3 LATCH PIN HOUSING SET SCREWS 98410236 2 1/4”-20 X 2.75” SHCS ZINC
BASE HARDWARE KIT -- 240105
C1 COUPLER TUBE PIN 010019 1 5/8” PIN, .625 DIA.
C2 COUPLER PIN CLIP 98410143 1
C3 COUPLER TUBE SET BOLT 98010167 3 1/2”-13 X 1 1/2” BOLT
C4 COUPLER TUBE SET NUT 98150214 3 1/2”-13 HEAVY HEX NUT (7/8” HEX)
PINS AND CLIPS MOUNTING KIT -- 080601
E MOUNTING PIN 08060001 4
F MOUNTING PIN CLIP 98410127 4
BASE RAIL KIT
PULLRITE INDUSTRY STANDARD BASE RAILS ARE SOLD SEPARATELY. CALL (800) 443-2307 FOR MORE INFORMATION.
TORQUE TABLE
Hardware Size Torque Specs
Latch Pin Housing Set Screws 1/4” 5 ft. lbs.; factory assembled
Adapter Plate Set Screws 3/8” 20 ft. lbs.; both bolt and set nut,
must be torqued after
installing Adapter Plate
Bolts
Coupler Tube Set Bolts 1/2” 45 ft. lbs.; both bolt and set nut
Adapter Plate Bolts 1/2” 75 ft. lbs.; torque before Adapter
Plate Set Screws
