Pulsar Axion 2 LRF XQ35 User Manual

Image not found or type unknown

1.
Install the APS 5 battery (15) in the battery compartment (14) of the device.
2.
Connect the USB cable (19) to the USB Type-C connector (9) of the device.
3.
Connect the other end of the USB cable (19) to the Power Adapter (20).
4.
Plug the Power Adapter (20) into a 100-240 V socket.
5.
Wait until the battery is fully charged (indication in the status bar:
Image not found or type unknown
).
Option 2

Pulsar Axion 2 LRF XQ35 Specifications

General

Sensor Resolution	384x288
Pixel Pitch	17 µm
NETD	<40 mK
Objective Lens	F35/1.0
Magnification	2x - 8x
Display Type	AMOLED
Built-in memory	16 GB
Wi-Fi	Yes
Protection degree	IPX7
Weight	0.35 kg
Laser Rangefinder	Yes
Wavelength	905 nm
Accuracy	±1 m
Frame Rate	50 Hz
Display Resolution	640x400
Video / Photo resolution	528x400
Video / Photo format	MP4, JPG
Frequency	2.4 GHz
Battery Type	APS5
Battery Life	11 hours
LRF Range	1000 m
Field of View	10.7x8°
Operating temperature	-25°C to +50°C
