Pulsar Axion 2 LRF XQ35 User Manual

Button Operation
Operation Button
Power device on short press
Power device off long press for 3 secs
Turn display off long press for less than 3 secs
Turn display on short press
Calibrate the microbolometer short press
Switching amplification levels short press
Control discrete digital zoom long press
Laser Rangefinder Button
Turn on rangefinder short press
Single distance measurement short press
Activate rangefinder scan mode long press
Deactivate rangefinder scan mode short press
Turn off rangefinder 󰾬long press
Main Menu Button
Enter main menu long press
Navigation upwards/rightwards short press
Navigation downwards/leftwards short press
Confirm selection short press
Exit submenu without confirming
selection
long press
Exit menu (switch to viewing mode) long press
Quick Menu Button
Enter quick menu short press
Switch between quick menu options short press

Pulsar Axion 2 LRF XQ35 Specifications

General

Sensor Resolution	384x288
Pixel Pitch	17 µm
NETD	<40 mK
Objective Lens	F35/1.0
Magnification	2x - 8x
Display Type	AMOLED
Built-in memory	16 GB
Wi-Fi	Yes
Protection degree	IPX7
Weight	0.35 kg
Laser Rangefinder	Yes
Wavelength	905 nm
Accuracy	±1 m
Frame Rate	50 Hz
Display Resolution	640x400
Video / Photo resolution	528x400
Video / Photo format	MP4, JPG
Frequency	2.4 GHz
Battery Type	APS5
Battery Life	11 hours
LRF Range	1000 m
Field of View	10.7x8°
Operating temperature	-25°C to +50°C
