Pulsar CORE FXQ50 User Manual

16
17
Eventually the auxiliary cross should match the point of impact, with the
sight's reticle being held in the aiming point.
To save display calibration parameters, keep the “MODE” button (or (23)
RC button) pressed for two seconds - display will show “OK” message; the
image of the target centre should now coincide with the centre of the of
sight's reticle.
To restore factory settings, select “Yes” in the item “Default settings”.
Parameters as follows are restored to factory settings:
Operating mode – “Forest”;
Image calibration mode – automatic;
Brightness of menu symbols – 5;
Display calibration – coordinates X=0, Y=0;
Magnification – x1;
Color inversion - off;
Brightness settings – 10;
Contrast settings – 6.
Note. Auxiliary menu items (“Display calibration” and “Default settings”)
are only available when the unit is in attachment mode.
While holding the reticle in the aiming point, move the auxiliary cross to the
point of impact with buttons “LEFT” or “RIGHT” (or RC buttons (22),(24). To
switch movement direction from horizontal to vertical, press button “MODE”
or (23) RC button. Horizontal/vertical travel range of the auxiliary cross
relative to the limiting frame is +/-10.
NOTES
