ENGLISH
Powering on and image setup
• Remove the lens cover (1) by turning it counterclockwise.
• Press the ON button (9) to turn on the thermal imager.
• Adjust the eyepiece dioptre ring of your daylight optical device until the
symbols in the display are sharp. In future, it will not be necessary to adjust
the eyepiece dioptre, regardless of the distance and other conditions.
• Rotate the lens focus knob (10) to focus on the visual target.
• Enter the main menu with a long press of the MENU button (7) and select the
desired calibration mode: manual (M), semi-automatic (SA) or automatic (A).
• Calibrate the image by briey pressing the ON button (9). Close the lens
cover when calibrating manually.
• Select the desired observation mode (Forest, Rocks, or User)
by briey pressing the MODE button (8) or in the main menu. User mode
allows you to change and save user brightness and contrast settings in the
quick menu.
• Select one of the two color palettes by a long press of the MODE button (8).
• Activate the quick menu by briey pressing the MENU button (7) to adjust the
brightness and contrast of the display (see the Quick Menu Functions section
of the full version manual for details).
• Upon completion of use turn the device off by a long press of the ON button (9).
Stream Vision App
Download the Stream Vision app to stream the image (via Wi-Fi) from your
device to a smartphone or tablet, to view recorded les and update the
software on the device. A detailed user guide is available at pulsar-vision.com
6
