Pulsar Merger LRF User Manual

Button Operation
Operation Button
Power device on short press
Power device off long press for 3 secs
Turn display off
(if the proximity sensor is off)
long press for less than 3
secs
Turn display on
(if the proximity sensor is off)
short press
Calibrate the microbolometer short press
Control discrete digital zoom short press
PiP on/off long press
Switching amplification levels short press
Turn on/off the White Hot
palette
long press
Video Recorder Button
Start/pause/resume video
recording
short press
Stop video recording long press
Switch to video / photo long press
Capture Photo short press
Main Menu Button
Enter main menu long press
Navigation upwards/rightwards short press
Navigation
downwards/leftwards
short press
Confirm selection short press

Pulsar Merger LRF Specifications

General

Waterproof	IPX7
Range Finder	Yes
Range Finder Accuracy	± 1 m
Laser rangefinder wavelength	905 nm
Battery Type	Li-ion
Operating temperature	-20°C to +50°C
