Pulsar Merger LRF User Manual

Specifications
XP50 PRO
Model XP50
SKU 77465
Microbolometer

Type uncooled
Resolution, pixels 640x480
Pixel Pitch, µm 17
NETD, mK < 25
Frame rate, Hz 50
Optical Characteristics

Lens, mm F50 F/1.0
Continuous digital zoom, x 2.5-20
Digital zoom 2x/4x/8x
Minimum Focus Distance, m/y 5 / 5.47
Eye relief, mm/inch 15 / 0.59
Exit pupil diameter, mm 3.5
Field of view (HxV), degrees /
m@100m
12.4 / 21.8
Diopter adjustment, D ±5
Interpupillary distance
adjustment, mm
56-71
Range of detection (deer type
object), m/y
1800 / 1970
Display


Pulsar Merger LRF Specifications

General

Waterproof	IPX7
Range Finder	Yes
Range Finder Accuracy	± 1 m
Laser rangefinder wavelength	905 nm
Battery Type	Li-ion
Operating temperature	-20°C to +50°C
