Control Switches
A
B
C
D
C. Horn Button : ( ) Press button for
sounding horn.
D. Pass Switch : Press the switch to flash
the head light. It is used to give signal to
vehicles coming from opposite side while
overtaking.
Left Handle Bar Switches
A. High/Low Switch : When headlight is ON,
High or Low beam can be selected with
this switch. Hi beam indicator light located
on Speedo console will light up when high
beam is selected.
: High Beam : Low beam
B. Turn Signal Switch : When the turn signal
knob is pushed to Left ( ) or Right ( )
respective indicator will start blinking, to
exit push the knob in & release.
13
