Pulsar PWE1600 User Manual

6
ASSEMBLY INSTRUCTIONS
Unpacking The Carton
After opening the carton, please remove all parts and check them against the following
list of components that are included:
A. High Pressure Washer D. Adjustable Nozzle
B. Gun E. Water Intake Filter (Pre-Installed)
C. High Pressure Hose F. Two-Way Connector
To assemble the enclosed parts, please refer to the steps that follow:
1600 PSI Pressure Washer
E
F
D
Step 1
1600 PSI Pressure Washer
- Take the hose lock to position A to unlock.
- Attach the high pressure hose to the gun.
- Then push the hose lock to position B to lock the
fitting.
A
B
A
B
B
D
7
Step 2
Insert the adjustable spray nozzle into the gun. Push and turn the adjustable nozzle
clockwise onto the gun until it is hand tight and
t
o lock it in place. When the pieces
are joined
properly, you cannot separate the two components by pulling out on the
adjustable nozzle. All attachments must be inserted into the gun for proper use.

Pulsar PWE1600 Specifications

General

Brand	Pulsar
Model	PWE1600
Category	Pressure Washer
Language	English
